Position Indicator Limit Switch Box
A. The Position Indicator Limit Switch Box is a device used to indicate the position of a valve or actuator.
B. It features a compact design, durable construction, and easy installation.
C. The box provides accurate and reliable feedback for monitoring and controlling industrial processes.
Description
The Position Indicator Limit Switch Box is a crucial component in industrial processes that require monitoring and controlling the position of valves or actuators. This device serves to provide accurate and reliable feedback, ensuring smooth operation and preventing potential malfunctions.
Features
A. Robust and Flexible Case design. Die-cast Aluminum Case and Powder Coating.
B. Fastener fastening visual position indicator.
C. Quick setting cam. The spring preload spline coupling cam does not need to be set again after the first setting. Easy to debug without tools.
D. Two-way cable interface.
E. Anti-loose end cap bolt, no need to worry about bolt loosening spring preload end cap bolt when opening the cover.
F. Easy to install bracket, NAMUR standard stainless steel rotating shaft and stainless steel or carbon steel bracket.
Parameter
|
Body case type |
Protective ip67/NEMA 4&4X flameproof type |
|
Cable interface |
2NPT3/4’’ |
|
Ambient temperature |
-20℃~80℃ |
|
End |
8heads(0.08-2.5mm) |
|
Position indicator |
0~9°(90 automatic rotation )off:red;on:yellow |
|
Switch |
Mechanich switch,proximity switch |
|
Coating |
Chromate polyester powder coating(black) |
Ordering Information
① Enclosure type
2: Weather proof
② Switch type
10: 2-SPDT
20: Proximity Sensor
③ Enclosure Material
N: Aluminum Die-casting
3. Standard specification
Model APL-2..N
Enclosure Rated Weatherproof IP67/NEMA type 4X (Standard), IP68(Option)
Enclosure High grade aluminum alloy
Ambient Temperature -20 ℃ ~ + 80 ℃
Conduit Entries Standard: Two 1/2" NPT, Option: PF1/2”, PT1/2”, M20, PG13.5
Travel Angle 90 degree +/- 10%
Position Indicator Open : Yellow, Close : Red
Language : English
Switch Mechanical switch:
Proximity sensor:
Terminal Strip 8 point (option : 9~14P)
External Coating Thermally hardened polyester powder coating
One of the most significant advantages of the Position Indicator Limit Switch Box is its ability to work in a wide range of environments. Whether it is used in harsh weather conditions, dirty and dusty locations, or environments with high vibration levels, this product is up to the task. It has been tested and certified to meet all relevant safety standards and ensures complete reliability in even the most challenging conditions.
