Magnetic Switch Position Indicator

In industries where monitoring the position of moving parts is crucial, having a reliable and efficient solution is paramount. This is where the Magnetic Switch Position Indicator comes into play. This innovative device utilizes magnetic technology to provide accurate and real-time position indication, improving safety and efficiency in various applications.



Accurate Position Monitoring

The magnetic switch indicator is designed to accurately monitor the position of moving components. By utilizing magnetic field sensing, the indicator detects the proximity of a magnet embedded in the moving part. This allows for precise and reliable position monitoring, ensuring that operators have real-time information about the status and location of the component.



Magnetic Field Sensing for Reliable Detection

At the core of this switch indicator is its magnetic field sensing mechanism. This technology enables the indicator to detect the presence or absence of a magnetic field with high sensitivity. As the magnet on the moving part approaches the indicator, the magnetic field is sensed, triggering the switch to indicate the position. This ensures that the indication is accurate and consistent, even in demanding industrial environments.



Versatility in Applications

The magnetic switch indicator finds applications in a wide range of industries and processes. From manufacturing plants to material handling equipment, this device offers a versatile solution for position monitoring. It can be used to track the position of doors, gates, valves, conveyors, and other moving components, enhancing operational efficiency and safety.



Easy Installation and Integration

One of the key advantages of the Magnetic Switch Position Indicator is its ease of installation and integration into existing systems. The indicator can be conveniently mounted using various methods, such as screws or adhesive tapes, depending on the application requirements. Additionally, it can be easily integrated into control systems, allowing for seamless integration and compatibility.



Enhanced Safety and Efficiency

By providing real-time position indication, the magnetic switch indicator significantly enhances safety in industrial environments. Operators can monitor the position of moving parts, ensuring that they are in the correct position and avoiding potential accidents or hazards. Moreover, this device improves efficiency by providing operators with instant information, allowing for quick decision-making and optimizing workflow.



Safety Enhancement

The magnetic switch indicator contributes to safety by preventing unauthorized access to restricted areas. When used on doors or gates, it can detect whether they are fully closed or open, triggering alarms or safety measures if necessary. This helps maintain a secure working environment and prevents accidents or intrusions.



Operational Efficiency

Efficiency is a critical aspect of any industrial process. With the magnetic switch indicator, operators have real-time information about the position of moving parts, enabling them to optimize processes and reduce downtime. It streamlines workflow, improves productivity, and minimizes errors or delays associated with manual position monitoring.





• Mini design without extral bracket
• Easy and fast installation
• Connection applies with NAMUR standard
• Universal voltage for AV and DC
• 2 LED full stroke position indication
• Anti-water,anti-corrosion, 2 position sensor is epoxy coating
• Electric wiring control which is safe and without spark
• No wearing electric components





Temp.Range	-45℃~+85℃
Sense Type	magnetic
Sense Distance	1~6mm
Contact Type	NO(NC Option)
On/off frequency	0~4.8KHz
Rotation indication	0~90°
voltage	5~240VAC/VDC
current	0~300mA
Rating power	10W
Protection class	1p67
